Use the command first, then set or draw the boundary. Trims a block's visible area using a boundary line. (Uses your computer language settings) XCLIP SPELLįor all those engineers out there that can't spell, use this to spell check all your text. Definitions will be kept in your drawing to reference later. Importing Block DefinitionsĪfter the INSERT command and selecting the file, press the ESC key at your first prompt. Quickly creates a surface between two predefined curves. Orients text to a specified angle or most readable angle. Anything on this layer will show up in model and paper space, but won't plot. Default NO PLOT LayerĬreates a layer called DEFPOINTS. Quick dimension creation after object selection. Perfect for the AutoCAD perfectionists out there. OVERKILLĭeletes any duplicate or overlapping items. You can adjust your default scale factor by setting the Auxiliary scale factor to Plot Scale or Dimscale. IDĭisplays point coordinates throughout your worksheet. DIMBASELINEĬreates a dimension that starts from a baseline of earlier dimensions that is linear, angular or coordinate. Especially useful for images like company logos, etc. This lets you insert that image as a drawing, instead of the image, and all settings are kept the same. After your image is how you want it, save the drawing. Instead of scaling and rotating images each time, simply insert the image into a blank drawing and set its position, scale, and rotation. APPLOADĪllows you to set which application to load in conjunction with opening AutoCAD. Setting this value to 1 allows dialog boxes to open in AutoCAD, setting it to 0 means everything is done in the command line. Instead of using CTRL-Z, OOPS undoes your last erase command without affecting any work you have done since then.
OOPS does exactly what you think it does, it fixes your mistake (as long as it's a delete) no matter how far back it was. Especially useful for bringing XREF linework into current drawings. NCOPYĬopies linework or objects from a nested object into your current drawing. BURSTīURST allows you to explode a block/object without losing any of its attributes. CHSPACEĪllows you to move objects in a drawing from layout to model space by choosing a viewport to push the text or objects into. For all the AutoCAD users out there, from new to expert, here are the top 50 AutoCAD tricks, commands, and shortcuts from across the web.
